Power Data
* Power supply: 3 x 230-400Vac, -15%+10%, 50Hz
* Motor power ratings from 4kW to 22kW
* Overload: 200% for 10 seconds
* Motor type: Asynchronous

EMC & Mark Compliances:

• Integrated EMI Filter for EN 12015; EN 61800-3 2nd environment, category C2 and C3
• CE Mark
• Conforms to UNI EN 81-1:1998 + A3:2009, article 9.11.3

Main Features

• Multispeed control
• Short floor management
• Emergency single-phase power supply for floor return with low energy optimization
• Flexible ramp management
• Integrated braking unit
• Communication with control board via I/O
• Management of TTL incremental digital encoders
• Integrated EMI filter for versions (VDL200….-F)

Product Set-Up

• The configuration set-up can be done by the following:
• Optional alphanumeric keypad (KB-ADL)
• PC with Graphical User Interface GF-eXpress

Easy and safe start-up
Thanks to the Wizard and the different access profiles (easy and expert) the configuration of the drive is fast and intuitive. The still autotuning is quickly performed, avoiding operators to decouple the car from the ropes, assuring a safe working environment and a faster commissioning.

Options

• KB-ADL multilingual programming keypad with memory (up to 5 configurations)
• Dedicated external EMC filters (for version without integrated EMC Filter).
• External braking resistors
• AC and DC input chokes
