Description
Alicat PC series pressure controllers utilize the same valves used in Alicat’s mass flow controller line resulting in fast and accurate pressure control. With a fully functional digital display and a host of other standard features Alicat’s PC series line of pressure controllers are a feature rich solution for applications requiring precise pressure control.
Benefits
Precise
Alicat’s PC series pressure controller is more precise than standard manual regulator pressure controller.
Versatile
A variety of output options including 0-5V, 0-10V and 4-20mA and RS-232 allow users to tailor the PC series pressure controller to their application. Modular design allows PC series pressure control instruments to be configured for use in vacuum control applications as well as pressure control applications. PC instruments are available in ranges from 4″H20 PSIG through 100PSIG; 15PSIA through 100PSIA; 4″H20PSID through 150PSID.
Fast
With a 50ms response time, Alicat PC series pressure controllers are ideal for a variety of applications in which precise and stable pressure control are a requirement.
Cheap to operate
Alicat PC seris pressure controller require very low power to operate and when used properly require minimal maintenance.
Rugged
Standard 302SS (optional 316S) flow body with aluminum case housing looks good and provides long service life.
Accurate and Repeatable
Accurate to +/-0.5% of FS and repeatable to +/-0.5% of full scale.
All Alicat PC series pressure controller calibrations are NIST traceable.
Features
Alicat PC series pressure controllers come standard with the following options:
- Fully functional digital display with pushbutton control
- No warm up time
- Viton seals
- 8 pin mini din electronic connector
- Standard barrel type power connector
- RS-232 Multi-drop digital output
- RS-232 Multi-drop digital input
- Choice of 0-5Vdc, 0-10Vdc, or 1-5Vdc analog output
- Choice of 0-5Vdc, 0-10Vdc, 1-5Vdc, or 4-20mA analog input
- User tunable PID algorithm
- Multiple digital & analog input/output
- 200:1 turndown ratio allow gauge to measure 1/200th of its full scale potential
- User can select any of nine units of measure at time of order
- Setpoint control and loop tuning via display
- Able to operate in applications with flow rates as high as 2500SLPM.
- Compatible with a variety of gases and liquids
- NPT process connections
- Lifetime warranty
Optional features and equipment
- High accuracy calibration
- Locking 6 pin, DB9 or DB15 connector
- DeviceNet™ digital input/output
- ProfiBUS digital input/output
- RS-485 digital input/output
- 4-20mA analog output
- Color backlit TFT display
- Remote panel mount display
- Remote panel mount color backlit TFT display
- Acrylic Mil-spec dielectric conformal coating
- EPDM seals
- NeSSI flow body
- Oxygen cleaned
- Remote electronic package for high temp environments
- SAE process connections
- VCR, VCO style welded fittings
- 5VDC, 12VDC, 24VDC, or open drain flow alarms (high or low)
- Additional calibration points
- Stainless steel valves
- High flow, low drop valve
- Internal potentiometer control
- CSA or ATEX certification
