Rohde-schwarz-Single/Dual Channel Analyzer/Power Supply (Model:R&S®NGMO)

The R&S®NGMO analyzer/power supply is more than just a simple power supply for test and measurement applications. This is shown by its advanced features:

• Accurate high-speed voltage source
• Programmable DC load
• Precise digital voltmeter
• Transient recorder
• Simple squarewave generator delivering high output power

Two models of R&S®NGMO are available: The R&S®NGMO1 single-channel analyzer/ power supply and the R&S®NGMO2 dual-channel analyzer/power supply. The R&S®NGMO2 provides all the above listed features two times, without any down-specification of the 2nd channel. Both channels are totally equivalent. Two independent channels (R&S®NGMO2), installed in an enclosure which is ½ 19" wide and only two height units, ensure a simple and accurate power supply for battery-operated mobile-radio products now and in the future. The outside view and the channel specification of R&S®NGMO1 and R&S®NGMO2 is the same.

• • Two channels (R&S®NGMO2)
  • Fast load regulation
  • Result memory for fast current and voltage measurements
  • Internal and external triggers
  • Two separate voltage measurement channels
  • Sinking to 2.8 A (static)
  • High-resolution voltage settings
  • Precise measurements in μA range
  • Minimal ripple and noise
  • Adjustable output impedance for battery emulation
  • OVP/OCP
  • Detection of open sense pins
  • Auxiliary inputs/outputs (output inhibit, relay, complete, trigger)
  • Compact design (2 HU, ½ 19")
  • IEEE488.2, RS-232-C
  • Fast programming
  • Convenient manual operation
