Key Facts
- Frequency range from 9 kHz to 40 GHz
- Wide dynamic range of up to 140 dB
- Short sweep times of 4 ms for 401 points
- High temperature stability of typ. 0.01 dB/°C
- Wide power sweep range of 98 dB
- Wide range of IF bandwidths from 1 Hz to 10 MHz
- Manual and automatic calibration
- Large, high-resolution 12.1" screen
- Touchscreen user interface
- Two or four test ports
- Four-port model with two independant generators
Features & Benefits
-
Designed to meet the highest standards
- Wide dynamic range from 9 kHz for fast measurements on high-blocking DUTs
- Excellent raw data for high basic accuracy
- High temperature stability for long calibration intervals
- Fast synthesizers for high measurement speed
-
Convenient characterization of active and passive RF components
- Fast embedding/de-embedding for impedance matching using virtual networks
- Mixed-mode S-parameters for balanced DUT characterization
- Extensive analysis functions for convenient trace analysis
- Amplifier measurements with wide power sweep range and receiver step attenuators
- Time domain analysis for distance-to-fault (DTF) measurements and filter adjustment
- Frequency conversion measurements on mixers and amplifiers – fast and simple with two independent internal generators
-
Network analysis made easy
- Flat and clear menu structures for efficient operation
- Optimal display configuration for each measurement task
-
Simple calibration – manual or automatic
- The right calibration method for every test application
- TSM (Through, Short, Match) – full calibration in only five steps
- Simple and error-free – automatic calibration in 30 seconds
-
Measurements with up to 32 ports
- More ports by use of switch matrices
- Easy configuration at the push of a button
- Automatic calibration units for accurate measurements
-
High throughput in production
- Short measurement times
- High measurement speed due to wide dynamic range and optimized IF bandwidths
- Segmented sweep for high speed and accuracy
- Fast switching between instrument setups
-
A worthwhile investment
- Ready for the future
- Upgrading test systems without rewriting system software
- An analyzer that speaks the user's language
Brief Description
More than 60 years of experience in the field of vector network analysis pay off: Rohde & Schwarz once again sets new benchmarks – with the R&S®ZNB vector network analyzers. The new family of network analyzers features high measurement speed, outstanding precision and exceptional ease of operation.
